| Specifications |
| Operating weight | 2000 kg |
| Bucket capacity | 0.04m³ |
| Dozer blade width(extend/retract) | 990/1240 mm |
| Dozer blade height | 270 mm |
| Track length | 1450 mm |
| Wheel spacing | 1120 mm |
| Engine / Dimensions |
| Model | Kubota D722 |
| Power | 10.2kw |
| Length*Width*Height | 3300*1110*2360 mm |
| Standard bucket width(with/without side teeth) | 440/400 mm |
| Min.turning radius at front end | 1660 mm |
| Track center distance | 883 mm |
| Boom height | 2635 mm |
| Performance |
| Max.excavation height | 3310 mm |
| Max.unloading height | 2370 mm |
| Max.excavation depth | 2120 mm |
| Max. excavation distance | 3640 mm |
| Max.vertical digging depth | 1535 mm |
| Max.digging ground distance | 3570 mm |
