Descripción
PRODUCT DETAIL
ACCESORIES
| Specifications | |
| Operating weight | 1200 kg |
| Bucket capacity | 0.022m³ |
| Swing speed | 9rpm |
| Max.toque | 25/2500N.m/r/min |
| Max.gradeability | 30° |
| Max.travel speed | 1.8km/h |
| Engine / Dimensions | |
| Model | Koop192FA |
| Power | 7.6kw 3000rpm |
| Length*Width*Height | 2890*930*2285 mm |
| Max. digging force | 6.5kN |
| Min.turning radius | 1490 mm |
| Max.dozing height | 170 mm |
| Max.dozing depth | 240 mm |
| Performance | |
| Max.digging height | 2490 mm |
| Max.unloading height | 1745 mm |
| Max.digging depth | 1725 mm |
| Max. excavation distance | 3030 mm |
| Max.vertical digging depth | 1655 mm |
| Max.digging ground distance | 2940 mm |
